Product Type: | Rabbit polyclonal IgG, primary antibodies |
---|---|
Species reactivity: | Human, Mouse |
Applications: | WB, IF-Cell, IHC-P, FC |
Clonality: | Polyclonal |
Form: | Liquid |
Storage condition: | Store at +4℃ after thawing. Aliquot store at -20℃ or -80℃. Avoid repeated freeze / thaw cycles. |
Storage buffer: | 1*PBS (pH7.4), 0.2% BSA, 40% Glycerol. Preservative: 0.05% Sodium Azide. |
Concentration: | 1ug/ul |
Purification: | Immunogen affinity purified. |
Molecular weight: | Predicted band size: 33 kDa |
Isotype: | IgG |
Immunogen: | Synthetic peptide corresponding to Human CD80 / B7-1 aa 71-120 / 288. |
Positive control: | Human brain tissue lysate, K562 cell lysate, N2A, SHG-44, human tonsil tissue, mouse lung tissue, mouse spleen tissue, Hela. |
Subcellular location: | Membrane. |
Recommended Dilutions:
WB IF-Cell IHC-P FC |
1:500-1:2,000 1:50-1:200 1:100-1:500 1:50-1:100 |
Uniprot #: | SwissProt: P33681 Human | Q00609 Mouse |
Alternative names: | Activation B7-1 antigen B lymphocyte activation antigen B7 B7 B7-1 B7-1 antigen B7.1 BB1 CD28 antigen ligand 1 CD28LG CD28LG1 CD80 CD80 antigen (CD28 antigen ligand 1, B7-1 antigen) CD80 antigen CD80 molecule CD80_HUMAN Costimulatory factor CD80 costimulatory molecule variant IgV-CD80 CTLA-4 counter-receptor B7.1 LAB7 T-lymphocyte activation antigen CD80 |
Fig1:
Western blot analysis of CD80/B7-1 on different lysates with Rabbit anti-CD80/B7-1 antibody (1007-8) at 1/2,000 dilution. Lane 1: Human brain tissue lysate (20 µg/Lane) Lane 2: K562 cell lysate (10 µg/Lane) Predicted band size: 33 kDa Observed band size: 60 kDa Exposure time: 2 minutes; 10% SDS-PAGE gel. Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (1007-8) at 1/2,000 dilution was used in 5% NFDM/TBST at room temperature for 2 hours. Goat Anti-Rabbit IgG - HRP Secondary Antibody (HA1001) at 1:300,000 dilution was used for 1 hour at room temperature. |
|
Fig2:
ICC staining CD80 in N2A cells (green). The nuclear counter stain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X100/PBS. |
|
Fig3:
ICC staining CD80 in SHG-44 cells (green). The nuclear counter stain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X100/PBS. |
|
Fig4:
Immunohistochemical analysis of paraffin-embedded human tonsil tissue using anti-CD80 antibody. Counter stained with hematoxylin. |
Fig5:
Immunohistochemical analysis of paraffin-embedded mouse lung tissue using anti-CD80 antibody. Counter stained with hematoxylin. |
|
Fig6: Immunohistochemical analysis of paraffin-embedded mouse spleen tissue using anti-CD80 antibody. Counter stained with hematoxylin. | |
Fig7: Flow cytometric analysis of Hela cells with CD80 antibody at 1/50 dilution (red) compared with an unlabelled control (cells without incubation with primary antibody; black). Alexa Fluor 488-conjugated goat anti-rabbit IgG was used as the secondary antibody. |
