ER1804-03

CD163 Rabbit Polyclonal Antibody

cat.: ER1804-03

Product Type:	Rabbit polyclonal IgG, primary antibodies
Species reactivity:	Human, Mouse, Rat
Applications:	WB, IHC-P, IF-Cell
Clonality:	Polyclonal

Form:	Liquid
Storage condition:	Store at +4℃ after thawing. Aliquot store at -20℃. Avoid repeated freeze / thaw cycles.
Storage buffer:	1*PBS (pH7.4), 0.2% BSA, 50% Glycerol. Preservative: 0.05% Sodium Azide.
Concentration:	1ug/ul
Purification:	Immunogen affinity purified.
Molecular weight:	Predicted band size: 125 kDa, observed band size: 150 kDa.
Isotype:	IgG
Immunogen:	Recombinant protein within Human aa 22-161 / 1,156.
Positive control:	Human lung tissue lysate, human liver tissue lysate, LOVO, SH-SY5Y, Siha, A431, mouse liver tissue, rat lung tissue, human placenta tissue.
Subcellular location:	Secreted, Cell membrane.
Recommended Dilutions: WB IF-Cell IHC-P	1:500-1:1,000 1:50-1:200 1:50-1:600
Uniprot #:	SwissProt: Q86VB7 Human \| Q2VLH6 Mouse \| A0A8I5ZQF0 Rat
Alternative names:	C163A_HUMAN CD 163 CD163 CD163 antigen CD163 molecule Hemoglobin scavenger receptor M130 M130 antigen precursor Macrophage associated antigen MM130 OTTHUMP00000238617 OTTHUMP00000238618 OTTHUMP00000238619 OTTHUMP00000238620 SCARI1 Scavenger receptor cysteine rich type 1 protein M130 sCD163 Soluble CD163

Images

	Fig1: Western blot analysis of CD163 on different lysates with Rabbit anti-CD163 antibody (ER1804-03) at 1/1,000 dilution. Lane 1: Human lung tissue lysate Lane 2: Human liver tissue lysate Lysates/proteins at 40 µg/Lane. Predicted band size: 125 kDa Observed band size: 150-170 kDa Exposure time: 10 seconds; ECL: K1801; 4-20% SDS-PAGE gel. Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (ER1804-03) at 1/1,000 dilution was used in 5% NFDM/TBST at 4℃ overnight. Goat Anti-Rabbit IgG - HRP Secondary Antibody (HA1001) at 1/50,000 dilution was used for 1 hour at room temperature.
	Fig2: ICC staining of CD163 in LOVO cells (green). Formalin fixed cells were permeabilized with 0.1% Triton X-100 in TBS for 10 minutes at room temperature and blocked with 1% Blocker BSA for 15 minutes at room temperature. Cells were probed with the antibody (ER1804-03) at a dilution of 1:100 for 1 hour at room temperature, washed with PBS. Alexa Fluor®488 Goat anti-Rabbit IgG was used as the secondary antibody at 1/100 dilution. The nuclear counter stain is DAPI (blue).
	Fig3: ICC staining of CD163 in SH-SY5Y cells (green). Formalin fixed cells were permeabilized with 0.1% Triton X-100 in TBS for 10 minutes at room temperature and blocked with 1% Blocker BSA for 15 minutes at room temperature. Cells were probed with the antibody (ER1804-03) at a dilution of 1:200 for 1 hour at room temperature, washed with PBS. Alexa Fluor®488 Goat anti-Rabbit IgG was used as the secondary antibody at 1/100 dilution. The nuclear counter stain is DAPI (blue).

	Fig4: Immunocytochemistry analysis of Siha cells labeling CD163 with Rabbit anti-CD163 antibody (ER1804-03) at 1/200 dilution. Cells were fixed in 4% paraformaldehyde for 10 minutes at 37 ℃, permeabilized with 0.05% Triton X-100 in PBS for 20 minutes, and then blocked with 2% negative goat serum for 30 minutes at room temperature. Cells were then incubated with Rabbit anti-CD163 antibody (ER1804-03) at 1/200 dilution in 2% negative goat serum overnight at 4 ℃. Goat Anti-Rabbit IgG H&L (iFluor™ 488, HA1121) was used as the secondary antibody at 1/1,000 dilution. PBS instead of the primary antibody was used as the secondary antibody only control. Nuclear DNA was labelled in blue with DAPI.
	Fig5: Immunocytochemistry analysis of A431 cells labeling CD163 with Rabbit anti-CD163 antibody (ER1804-03) at 1/200 dilution. Cells were fixed in 4% paraformaldehyde for 10 minutes at 37 ℃, permeabilized with 0.05% Triton X-100 in PBS for 20 minutes, and then blocked with 2% negative goat serum for 30 minutes at room temperature. Cells were then incubated with Rabbit anti-CD163 antibody (ER1804-03) at 1/200 dilution in 2% negative goat serum overnight at 4 ℃. Goat Anti-Rabbit IgG H&L (iFluor™ 488, HA1121) was used as the secondary antibody at 1/1,000 dilution. PBS instead of the primary antibody was used as the secondary antibody only control. Nuclear DNA was labelled in blue with DAPI.
	Fig6: Immunohistochemical analysis of paraffin-embedded mouse liver tissue using anti-CD163 antibody. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 8.0-8.4) for 20 minutes.The tissues were blocked in 5% BSA for 30 minutes at room temperature, washed with ddH₂O and PBS, and then probed with the antibody (ER1804-03) at 1/200 dilution, for 30 minutes at room temperature and detected using an HRP conjugated compact polymer system. DAB was used as the chromogen. Counter stained with hematoxylin and mounted with DPX..
	Fig7: Immunohistochemical analysis of paraffin-embedded rat lung tissue using anti-CD163 antibody. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 8.0-8.4) for 20 minutes.The tissues were blocked in 5% BSA for 30 minutes at room temperature, washed with ddH₂O and PBS, and then probed with the antibody (ER1804-03) at 1/50 dilution, for 30 minutes at room temperature and detected using an HRP conjugated compact polymer system. DAB was used as the chromogen. Counter stained with hematoxylin and mounted with DPX.

Fig8: Immunohistochemical analysis of paraffin-embedded human placenta tissue using anti-CD163 antibody. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 8.0-8.4) for 20 minutes.The tissues were blocked in 5% BSA for 30 minutes at room temperature, washed with ddH₂O and PBS, and then probed with the antibody (ER1804-03) at 1/200 dilution, for 30 minutes at room temperature and detected using an HRP conjugated compact polymer system. DAB was used as the chromogen. Counter stained with hematoxylin and mounted with DPX.

Note: All products are “FOR RESEARCH USE ONLY AND ARE NOT INTENDED FOR DIAGNOSTIC OR THERAPEUTIC USE”.
