MEK1 Recombinant Rabbit Monoclonal Antibody [SZ22-01]
cat.: ET1603-20
Product Type: Recombinant Rabbit monoclonal IgG, primary antibodies
Species reactivity: Human, Mouse, Rat, Cow, Dog
Applications: WB, IF-Cell, IF-Tissue, IHC-P, IP, FC
Clonality: Monoclonal
Clone number: SZ22-01
Form: Liquid
Storage condition: Store at +4℃ after thawing. Aliquot store at -20℃ or -80℃. Avoid repeated freeze / thaw cycles.
Storage buffer: 1*TBS (pH7.4), 0.05% BSA, 40% Glycerol. Preservative: 0.05% Sodium Azide.
Concentration: 1ug/ul
Purification: Protein A affinity purified.
Molecular weight: Predicted band size: 43 kDa
Isotype: IgG
Immunogen: Synthetic peptide within N-terminal human MEK1.
Positive control: A431 cell lysate, HepG2 cell lysate, Hela cell lysate, MCF-7 cell lysate, NIH/3T3 cell lysate, human tonsil tissue, human breast carcinoma tissue, human kidney tissue, mouse pancreas tissue, mouse uterus tissue.
Subcellular location: Cytoplasm, Nucleus, Membrane, Cytoskeleton.
Recommended Dilutions:
  WB
  IF-Cell
  IF-Tissue
  IHC-P
  FC
  IP
1:500-1:2,000
1:50-1:200
1:50-1:200
1:50-1:200
1:50-1:100
Use at an assay dependent concentration.
Uniprot #: SwissProt: Q02750 Human | P31938 Mouse | Q01986 Rat
Alternative names: Dual specificity mitogen activated protein kinase kinase 1 Dual specificity mitogen-activated protein kinase kinase 1 ERK activator kinase 1 MAP kinase kinase 1 MAP kinase/Erk kinase 1 MAP2K1 MAPK/ERK kinase 1 MAPKK 1 MAPKK1 MEK 1 Mek1 MEKK1 Mitogen activated protein kinase kinase 1 MKK 1 MKK1 MP2K1_HUMAN PRKMK1 Protein kinase mitogen activated kinase 1 (MAP kinase kinase 1) Protein kinase mitogen activated, kinase 1
Images
ET1603-20_1.jpg Fig1: Western blot analysis of MEK1 on different lysates with Rabbit anti-MEK1 antibody (ET1603-20) at 1/2,000 dilution.

Lane 1: HCT 116-si NT cell lysate
Lane 2: HCT 116-si MEK1 cell lysate

Lysates/proteins at 10 µg/Lane.

Predicted band size: 43 kDa
Observed band size: 45 kDa

Exposure time: 8 seconds; ECL: K1801;

4-20% SDS-PAGE gel.

Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (ET1603-20) at 1/2,000 dilution was used in 5% NFDM/TBST at 4℃ overnight. Goat Anti-Rabbit IgG - HRP Secondary Antibody (HA1001) at 1/50,000 dilution was used for 1 hour at room temperature.
ET1603-20_2.jpg Fig2: Western blot analysis of MEK1 on different lysates. Proteins were transferred to a PVDF membrane and blocked with 5% BSA in PBS for 1 hour at room temperature. The primary antibody (ET1603-20, 1/500) was used in 5% BSA at room temperature for 2 hours. Goat Anti-Rabbit IgG - HRP Secondary Antibody (HA1001) at 1:5,000 dilution was used for 1 hour at room temperature.
Positive control:
Lane 1: A431 cell lysate
Lane 2: HepG2 cell lysate
Lane 3: Hela cell lysate
ET1603-20_3.jpg Fig3: ICC staining of MEK1 in Hela cells (green). Formalin fixed cells were permeabilized with 0.1% Triton X-100 in TBS for 10 minutes at room temperature and blocked with 1% Blocker BSA for 15 minutes at room temperature. Cells were probed with the primary antibody (ET1603-20, 1/50) for 1 hour at room temperature, washed with PBS. Alexa Fluor®488 Goat anti-Rabbit IgG was used as the secondary antibody at 1/1,000 dilution. The nuclear counter stain is DAPI (blue).
ET1603-20_4.jpg Fig4: ICC staining of MEK1 in MCF-7 cells (green). Formalin fixed cells were permeabilized with 0.1% Triton X-100 in TBS for 10 minutes at room temperature and blocked with 1% Blocker BSA for 15 minutes at room temperature. Cells were probed with the primary antibody (ET1603-20, 1/50) for 1 hour at room temperature, washed with PBS. Alexa Fluor®488 Goat anti-Rabbit IgG was used as the secondary antibody at 1/1,000 dilution. The nuclear counter stain is DAPI (blue).
ET1603-20_5.jpg Fig5: ICC staining of MEK1 in NIH/3T3 cells (green). Formalin fixed cells were permeabilized with 0.1% Triton X-100 in TBS for 10 minutes at room temperature and blocked with 1% Blocker BSA for 15 minutes at room temperature. Cells were probed with the primary antibody (ET1603-20, 1/50) for 1 hour at room temperature, washed with PBS. Alexa Fluor®488 Goat anti-Rabbit IgG was used as the secondary antibody at 1/1,000 dilution. The nuclear counter stain is DAPI (blue).
ET1603-20_6.jpg Fig6: Immunohistochemical analysis of paraffin-embedded human tonsil tissue using anti-MEK1 antibody. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 8.0-8.4) for 20 minutes.The tissues were blocked in 5% BSA for 30 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (ET1603-20, 1/50) for 30 minutes at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.
ET1603-20_7.jpg Fig7: Immunohistochemical analysis of paraffin-embedded human breast carcinoma tissue using anti-MEK1 antibody. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 8.0-8.4) for 20 minutes.The tissues were blocked in 5% BSA for 30 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (ET1603-20, 1/50) for 30 minutes at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.
ET1603-20_8.jpg Fig8: Immunohistochemical analysis of paraffin-embedded human kidney tissue using anti-MEK1 antibody. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 8.0-8.4) for 20 minutes.The tissues were blocked in 5% BSA for 30 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (ET1603-20, 1/50) for 30 minutes at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.
ET1603-20_9.jpg Fig9: Immunohistochemical analysis of paraffin-embedded mouse pancreas tissue using anti-MEK1 antibody. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 8.0-8.4) for 20 minutes.The tissues were blocked in 5% BSA for 30 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (ET1603-20, 1/50) for 30 minutes at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.
ET1603-20_10.jpg Fig10: Immunohistochemical analysis of paraffin-embedded mouse uterus tissue using anti-MEK1 antibody. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 8.0-8.4) for 20 minutes.The tissues were blocked in 5% BSA for 30 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (ET1603-20, 1/50) for 30 minutes at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.
ET1603-20_11.jpg Fig11: Flow cytometric analysis of MEK1 was done on Hela cells. The cells were fixed, permeabilized and stained with the primary antibody (ET1603-20, 1/50) (red). After incubation of the primary antibody at room temperature for an hour, the cells were stained with a Alexa Fluor 488-conjugated Goat anti-Rabbit IgG Secondary antibody at 1/1000 dilution for 30 minutes.Unlabelled sample was used as a control (cells without incubation with primary antibody; black).
Note: All products are “FOR RESEARCH USE ONLY AND ARE NOT INTENDED FOR DIAGNOSTIC OR THERAPEUTIC USE”.
