ERK1 Recombinant Rabbit Monoclonal Antibody [SP05-09]
cat.: ET1604-16
| Product Type: | Recombinant Rabbit monoclonal IgG, primary antibodies |
|---|---|
| Species reactivity: | Human, Mouse, Rat |
| Applications: | WB, IF-Cell, IF-Tissue, IHC-P |
| Clonality: | Monoclonal |
| Clone number: | SP05-09 |
| Form: | Liquid |
| Storage condition: | Store at +4℃ after thawing. Aliquot store at -20℃ or -80℃. Avoid repeated freeze / thaw cycles. |
| Storage buffer: | 1*TBS (pH7.4), 0.05% BSA, 40% Glycerol. Preservative: 0.05% Sodium Azide. |
| Concentration: | 1ug/ul |
| Purification: | Protein A affinity purified. |
| Molecular weight: | Predicted band size: 43 kDa |
| Isotype: | IgG |
| Immunogen: | Synthetic peptide within Human ERK1 aa 51-100 / 379. |
| Positive control: | HeLa cell lysate, Jurkat cell lysate, A549 cell lysate, Ramos cell lysate, MCF7 cell lysate, Neuro-2a cell lysate, C6 cell lysate, Hela, A431, NIH-3T3, mouse stomach tissue, human kidney tissue. |
| Subcellular location: | Cytoplasm, Nucleus. |
| Recommended Dilutions:
WB IF-Cell IF-Tissue IHC-P |
1:1,000-1:2,000 1:50-1:200 1:50-1:200 1:50-1:200 |
| Uniprot #: | SwissProt: P27361 Human | Q63844 Mouse | P21708 Rat |
| Alternative names: | ERK 1 ERK ERK-1 ERK1 ERT 2 ERT2 Extracellular Signal Regulated Kinase 1 Extracellular signal related kinase 1 Extracellular signal-regulated kinase 1 HGNC6877 HS44KDAP HUMKER1A Insulin Stimulated MAP2 Kinase Insulin-stimulated MAP2 kinase MAP kinase 1 MAP kinase 3 MAP Kinase MAP kinase isoform p44 MAPK 1 MAPK 3 MAPK MAPK1 Mapk3 MGC20180 Microtubule Associated Protein 2 Kinase Microtubule-associated protein 2 kinase Mitogen Activated Protein Kinase 3 Mitogen-activated protein kinase 1 Mitogen-activated protein kinase 3 MK03_HUMAN OTTHUMP00000174538 OTTHUMP00000174541 p44 ERK1 p44 MAPK p44-ERK1 p44-MAPK P44ERK1 P44MAPK PRKM 3 PRKM3 Protein Kinase Mitogen Activated 3 |
Images
|
Fig1:
Western blot analysis of ERK1 on different lysates with Rabbit anti-ERK1 antibody (ET1604-16) at 1/2,000 dilution. Lane 1: HeLa cell lysate Lane 2: Jurkat cell lysate Lane 3: A549 cell lysate Lane 4: Ramos cell lysate Lane 5: MCF7 cell lysate Lane 6: Neuro-2a cell lysate Lane 7: C6 cell lysate Lysates/proteins at 20 µg/Lane. Predicted band size: 43 kDa Observed band size: 43 kDa Exposure time: 10 seconds; ECL: K1801; 4-20% SDS-PAGE gel. Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (ET1604-16) at 1/2,000 dilution was used in 5% NFDM/TBST at 4℃ overnight. Goat Anti-Rabbit IgG - HRP Secondary Antibody (HA1001) at 1/50,000 dilution was used for 1 hour at room temperature. |
|
Fig2:
Immunocytochemistry analysis of Hela cells labeling ERK1 with Rabbit anti-ERK1 antibody (ET1604-16) at 1/50 dilution. Cells were fixed in 4% paraformaldehyde for 10 minutes at 37 ℃ , permeabilized with 0.05% Triton X-100 in PBS for 20 minutes, and then blocked with 2% negative goat serum for 30 minutes at room temperature. Cells were then incubated with Rabbit anti-ERK1 antibody (ET1604-16) at 1/50 dilution in 2% negative goat serum overnight at 4 ℃. Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) was used as the secondary antibody at 1/1,000 dilution. Nuclear DNA was labelled in blue with DAPI. |
|
Fig3:
Immunocytochemistry analysis of A431 cells labeling ERK1 with Rabbit anti-ERK1 antibody (ET1604-16) at 1/50 dilution. Cells were fixed in 4% paraformaldehyde for 10 minutes at 37 ℃ , permeabilized with 0.05% Triton X-100 in PBS for 20 minutes, and then blocked with 2% negative goat serum for 30 minutes at room temperature. Cells were then incubated with Rabbit anti-ERK1 antibody (ET1604-16) at 1/50 dilution in 2% negative goat serum overnight at 4 ℃. Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) was used as the secondary antibody at 1/1,000 dilution. Nuclear DNA was labelled in blue with DAPI. |
|
Fig4:
Immunocytochemistry analysis of NIH-3T3 cells labeling ERK1 with Rabbit anti-ERK1 antibody (ET1604-16) at 1/50 dilution. Cells were fixed in 4% paraformaldehyde for 10 minutes at 37 ℃ , permeabilized with 0.05% Triton X-100 in PBS for 20 minutes, and then blocked with 2% negative goat serum for 30 minutes at room temperature. Cells were then incubated with Rabbit anti-ERK1 antibody (ET1604-16) at 1/50 dilution in 2% negative goat serum overnight at 4 ℃. Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) was used as the secondary antibody at 1/1,000 dilution. Nuclear DNA was labelled in blue with DAPI. |
|
Fig5:
Immunohistochemical analysis of paraffin-embedded mouse stomach tissue with Rabbit anti-ERK1 antibody (ET1604-16) at 1/50 dilution. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (ET1604-16) at 1/50 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX. |
|
Fig6:
Immunohistochemical analysis of paraffin-embedded human kidney tissue with Rabbit anti-ERK1 antibody (ET1604-16) at 1/50 dilution. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (ET1604-16) at 1/50 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX. |
Note: All products are “FOR RESEARCH USE ONLY AND ARE NOT INTENDED FOR DIAGNOSTIC OR THERAPEUTIC USE”.
