Calnexin Recombinant Rabbit Monoclonal Antibody [SN20-54]
cat.: ET1611-86
| Product Type: | Recombinant Rabbit monoclonal IgG, primary antibodies |
|---|---|
| Species reactivity: | Human, Mouse, Rat |
| Applications: | WB, IP, IHC-P |
| Clonality: | Monoclonal |
| Clone number: | SN20-54 |
| Form: | Liquid |
| Storage condition: | Store at +4℃ after thawing. Aliquot store at -20℃ or -80℃. Avoid repeated freeze / thaw cycles. |
| Storage buffer: | 1*TBS (pH7.4), 0.05% BSA, 40% Glycerol. Preservative: 0.05% Sodium Azide. |
| Concentration: | 1ug/ul |
| Purification: | Protein A affinity purified. |
| Molecular weight: | Predicted band size: 68 kDa |
| Isotype: | IgG |
| Immunogen: | Synthetic peptide within Human Calnexin aa 543-592 / 592. |
| Positive control: | HeLa cell lysate, HepG2 cell lysate, MCF7 cell lysate, PANC-1 cell lysate, HAP1 cell lysate, human kidney tissue, human pancreas tissue, mouse kidney tissue, mouse liver tissue, rat kidney tissue, rat liver tissue, rat brain tissue. |
| Subcellular location: | Endoplasmic reticulum membrane, Endoplasmic reticulum, Melanosome. |
| Recommended Dilutions:
WB IP IHC-P |
1:1,000-1:2,000 1-2μg/sample 1:1,000-1:5,000 |
| Uniprot #: | SwissProt: P27824 Human | P35564 Mouse | P35565 Rat |
| Alternative names: | Calnexin CALX_HUMAN CANX CNX FLJ26570 Histocompatibility complex class I antigen binding protein p88 IP90 Major histocompatibility complex class I antigen-binding protein p88 p90 |
Images
|
Fig1:
Western blot analysis of Calnexin on different lysates with Rabbit anti-Calnexin antibody (ET1611-86) at 1/2,000 dilution. Lane 1: HeLa cell lysate Lane 2: HepG2 cell lysate Lane 3: MCF7 cell lysate Lane 4: PANC-1 cell lysate Lysates/proteins at 15 µg/Lane. Predicted band size: 68 kDa Observed band size: 100 kDa Exposure time: 2 minutes; 4-20% SDS-PAGE gel. Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (ET1611-86) at 1/2,000 dilution was used in 5% NFDM/TBST at 4℃ overnight. Goat Anti-Rabbit IgG - HRP Secondary Antibody (HA1001) at 1/50,000 dilution was used for 1 hour at room temperature. |
|
Fig2:
Western blot analysis of Calnexin on different lysates with Rabbit anti-Calnexin antibody (ET1611-86) at 1/1,000 dilution. Lane 1: HAP1-parental cell lysate Lane 2: HAP1-Calnexin KD cell lysate Lysates/proteins at 10 µg/Lane. Predicted band size: 68 kDa Observed band size: 90 kDa Exposure time: 180 seconds; ECL: K1802; 4-20% SDS-PAGE gel. Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (ET1611-86) at 1/1,000 dilution was used in 5% NFDM/TBST at 4℃ overnight. Goat Anti-Rabbit IgG - HRP Secondary Antibody (HA1001) at 1/50,000 dilution was used for 1 hour at room temperature. |
|
Fig3:
Immunohistochemical analysis of paraffin-embedded human kidney tissue with Rabbit anti-Calnexin antibody (ET1611-86) at 1/5,000 dilution. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (ET1611-86) at 1/5,000 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX. |
|
Fig4:
Immunohistochemical analysis of paraffin-embedded human pancreas tissue with Rabbit anti-Calnexin antibody (ET1611-86) at 1/2,000 dilution. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (ET1611-86) at 1/2,000 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX. |
|
Fig5:
Immunohistochemical analysis of paraffin-embedded mouse kidney tissue with Rabbit anti-Calnexin antibody (ET1611-86) at 1/1,000 dilution. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (ET1611-86) at 1/1,000 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX. |
|
Fig6:
Immunohistochemical analysis of paraffin-embedded mouse liver tissue with Rabbit anti-Calnexin antibody (ET1611-86) at 1/1,000 dilution. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (ET1611-86) at 1/1,000 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX. |
|
Fig7:
Immunohistochemical analysis of paraffin-embedded rat kidney tissue with Rabbit anti-Calnexin antibody (ET1611-86) at 1/1,000 dilution. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (ET1611-86) at 1/1,000 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX. |
|
Fig8:
Immunohistochemical analysis of paraffin-embedded rat liver tissue with Rabbit anti-Calnexin antibody (ET1611-86) at 1/1,000 dilution. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (ET1611-86) at 1/1,000 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX. |
|
Fig9:
Immunohistochemical analysis of paraffin-embedded rat brain tissue with Rabbit anti-Calnexin antibody (ET1611-86) at 1/1,000 dilution. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (ET1611-86) at 1/1,000 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX. |
|
Fig10:
Calnexin was immunoprecipitated from 0.2 mg HeLa cell lysate with ET1611-86 at 2 µg/25 µl agarose. Western blot was performed from the immunoprecipitate using ET1611-86 at 1/1,000 dilution. Anti-Rabbit IgG for IP Nano-secondary antibody (NBI01H) at 1/5,000 dilution was used for 1 hour at room temperature. Lane 1: HeLa cell lysate (input) Lane 2: ET1611-86 IP in HeLa cell lysate Lane 3: Rabbit IgG instead of ET1611-86 in HeLa cell lysate Blocking/Dilution buffer: 5% NFDM/TBST Exposure time: 1 minute 5 seconds; ECL: K1801 |
Note: All products are “FOR RESEARCH USE ONLY AND ARE NOT INTENDED FOR DIAGNOSTIC OR THERAPEUTIC USE”.
