STRAP / Unrip Mouse Monoclonal Antibody [A7H11]
cat.: HA601007
| Product Type: | Mouse monoclonal IgG1, primary antibodies |
|---|---|
| Species reactivity: | Human, Mouse, Rat |
| Applications: | WB, IHC-P, IF-Cell |
| Clonality: | Monoclonal |
| Clone number: | A7H11 |
| Form: | Liquid |
| Storage condition: | Store at +4℃ after thawing. Aliquot store at -20℃. Avoid repeated freeze / thaw cycles. |
| Storage buffer: | PBS (pH7.4), 0.1% BSA, 40% Glycerol. Preservative: 0.05% Sodium Azide. |
| Concentration: | 2ug/ul |
| Purification: | Protein G affinity purified. |
| Molecular weight: | Predicted band size: 38 kDa |
| Isotype: | IgG1 |
| Immunogen: | Recombinant protein within human STRAP aa 201-350/350. |
| Positive control: | HeLa cell lysate, HepG2 cell lysate, NIH/3T3 cell lysate, C6 cell lysate, PC-12 cell lysate, Mouse lung tissue lysate, HeLa, NIH/3T3, C6, human testis tissue. |
| Subcellular location: | Cytoplasm, Nucleus. |
| Recommended Dilutions:
WB IHC-P IF-Cell |
1:500 1:50-1:200 1:100 |
| Uniprot #: | SwissProt: Q9Y3F4 Human | Q9Z1Z2 Mouse | Q5XIG8 Rat |
| Alternative names: | MAP activator with WD repeats MAWD PTWD Serine-threonine kinase receptor-associated protein serine/threonine kinase receptor associated protein strap STRAP_HUMAN UNR-interacting protein UNRIP WD 40 repeat protein PT WD WD-40 repeat protein PT-WD |
Images
|
Fig1:
Western blot analysis of STRAP / Unrip on different lysates with Mouse anti-STRAP / Unrip antibody (HA601007) at 1/5,000 dilution. Lane 1: HeLa cell lysate Lane 2: HepG2 cell lysate Lane 3: NIH/3T3 cell lysate Lane 4: C6 cell lysate Lane 5: PC-12 cell lysate Lane 6: Mouse lung tissue lysate Lysates/proteins at 15 µg/Lane. Predicted band size: 38 kDa Observed band size: 38 kDa Exposure time: 20 seconds; ECL: K1801; 4-20% SDS-PAGE gel. Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (HA601007) at 1/5,000 dilution was used in primary antibody dilution (K1803) at 4℃ overnight. Goat Anti-Mouse IgG - HRP Secondary Antibody (HA1006) at 1/50,000 dilution was used for 1 hour at room temperature. |
|
Fig2:
Immunocytochemistry analysis of HeLa cells labeling STRAP / Unrip with Mouse anti-STRAP / Unrip antibody (HA601007) at 1/100 dilution. Cells were fixed in 4% paraformaldehyde for 15 minutes at room temperature, permeabilized with 0.1% Triton X-100 in PBS for 15 minutes at room temperature, then blocked with 1% BSA in 10% negative goat serum for 1 hour at room temperature. Cells were then incubated with Mouse anti-STRAP / Unrip antibody (HA601007) at 1/100 dilution in 1% BSA in PBST overnight at 4 ℃. Goat Anti-Mouse IgG H&L (iFluor™ 488, HA1125) was used as the secondary antibody at 1/1,000 dilution. PBS instead of the primary antibody was used as the secondary antibody only control. Nuclear DNA was labelled in blue with DAPI. beta Tubulin (ET1602-4, red) was stained at 1/100 dilution overnight at +4℃. Goat Anti-Rabbit IgG H&L (iFluor™ 594, HA1122) were used as the secondary antibody at 1/1,000 dilution. |
|
Fig3:
Immunocytochemistry analysis of NIH/3T3 cells labeling STRAP / Unrip with Mouse anti-STRAP / Unrip antibody (HA601007) at 1/100 dilution. Cells were fixed in 4% paraformaldehyde for 15 minutes at room temperature, permeabilized with 0.1% Triton X-100 in PBS for 15 minutes at room temperature, then blocked with 1% BSA in 10% negative goat serum for 1 hour at room temperature. Cells were then incubated with Mouse anti-STRAP / Unrip antibody (HA601007) at 1/100 dilution in 1% BSA in PBST overnight at 4 ℃. Goat Anti-Mouse IgG H&L (iFluor™ 488, HA1125) was used as the secondary antibody at 1/1,000 dilution. PBS instead of the primary antibody was used as the secondary antibody only control. Nuclear DNA was labelled in blue with DAPI. beta Tubulin (ET1602-4, red) was stained at 1/100 dilution overnight at +4℃. Goat Anti-Rabbit IgG H&L (iFluor™ 594, HA1122) were used as the secondary antibody at 1/1,000 dilution. |
|
Fig4:
Immunocytochemistry analysis of C6 cells labeling STRAP / Unrip with Mouse anti-STRAP / Unrip antibody (HA601007) at 1/100 dilution. Cells were fixed in 4% paraformaldehyde for 15 minutes at room temperature, permeabilized with 0.1% Triton X-100 in PBS for 15 minutes at room temperature, then blocked with 1% BSA in 10% negative goat serum for 1 hour at room temperature. Cells were then incubated with Mouse anti-STRAP / Unrip antibody (HA601007) at 1/100 dilution in 1% BSA in PBST overnight at 4 ℃. Goat Anti-Mouse IgG H&L (iFluor™ 488, HA1125) was used as the secondary antibody at 1/1,000 dilution. PBS instead of the primary antibody was used as the secondary antibody only control. Nuclear DNA was labelled in blue with DAPI. beta Tubulin (ET1602-4, red) was stained at 1/100 dilution overnight at +4℃. Goat Anti-Rabbit IgG H&L (iFluor™ 594, HA1122) were used as the secondary antibody at 1/1,000 dilution. |
|
Fig5:
Immunohistochemical analysis of paraffin-embedded human testis tissue with Mouse anti-STRAP / Unrip antibody (HA601007) at 1/200 dilution. The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH 6.0) for 2 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (HA601007) at 1/200 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX. |
Note: All products are “FOR RESEARCH USE ONLY AND ARE NOT INTENDED FOR DIAGNOSTIC OR THERAPEUTIC USE”.
