MAP2 Recombinant Antibody [PSH08-73] - Mouse IgG1 (Chimeric)
cat.: HA601458
| Product Type: | Recombinant Chimeric Antibody, primary antibodies |
|---|---|
| Species reactivity: | Mouse, Rat |
| Applications: | IHC-Fr, IHC-P, WB, IF-Cell |
| Clone number: | PSH08-73 |
| Form: | Liquid |
| Storage condition: | Shipped at 4℃. Store at +4℃ short term (1-2 weeks). It is recommended to aliquot into single-use upon delivery. Store at -20℃ long term. |
| Storage buffer: | PBS (pH7.4), 0.1% BSA, 40% Glycerol. Preservative: 0.05% Sodium Azide. |
| Concentration: | 1ug/ul |
| Purification: | Protein A affinity purified. |
| Molecular weight: | Predicted band size: 200 kDa |
| Immunogen: | Recombinant protein within human MAP2 aa 1-600. |
| Positive control: | Mouse brain tissue, rat brain tissue, Mouse brain tissue lysate, Rat brain tissue lysate, mouse primary neuronal cells. |
| Subcellular location: | Cytoplasm, cytoskeleton, Cell projection, dendrite. |
| Recommended Dilutions:
IHC-Fr IHC-P WB IF-Cell |
1:500 1:5,000 1:10,000 1:500 |
| Uniprot #: | SwissProt: P20357 Mouse | P15146 Rat |
| Alternative names: | DKFZp686I2148 MAP 2 MAP dendrite specific MAP-2 MAP2 MAP2A MAP2B MAP2C Microtubule associated protein 2 Microtubule-associated protein 2 MTAP2_HUMAN |
Images
|
Fig1:
Application: IHC-Fr Species: Mouse Site: brain Sample: Frozen section Antibody concentration: 1/500 Antigen retrieval: Not required |
|
Fig2:
Application: IHC-Fr Species: Rat Site: brain Sample: Frozen section Antibody concentration: 1/500 Antigen retrieval: Not required |
|
Fig3:
Immunohistochemical analysis of paraffin-embedded mouse brain tissue with Mouse anti-MAP2 antibody (HA601458) at 1/5,000 dilution. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (HA601458) at 1/5,000 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX. |
|
Fig4:
Immunohistochemical analysis of paraffin-embedded rat brain tissue with Mouse anti-MAP2 antibody (HA601458) at 1/5,000 dilution. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (HA601458) at 1/5,000 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX. |
|
Fig5:
Western blot analysis of MAP2 on different lysates with Mouse anti-MAP2 antibody (HA601458) at 1/10,000 dilution. Lane 1: Mouse brain tissue lysate Lane 2: Mouse kidney tissue lysate (negative) Lane 3: Rat brain tissue lysate Lysates/proteins at 20 µg/Lane. Predicted band size: 200 kDa Observed band size: 150-300 kDa Exposure time: 42 seconds; ECL: K1801; 4-20% SDS-PAGE gel. Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (HA601458) at 1/10,000 dilution was used in primary antibody dilution (K1803) at 4℃ overnight. Goat Anti-Mouse IgG - HRP Secondary Antibody (HA1006) at 1/50,000 dilution was used for 1 hour at room temperature. |
|
Fig6:
Immunocytochemistry analysis of mouse primary neuronal cells labeling MAP2 with Mouse anti-MAP2 antibody (HA601458) at 1/500 dilution. Cells were fixed in 4% paraformaldehyde for 15 minutes at room temperature, permeabilized with 0.1% Triton X-100 in PBS for 15 minutes at room temperature, then blocked with 1% BSA in 10% negative goat serum for 1 hour at room temperature. Cells were then incubated with Mouse anti-MAP2 antibody (HA601458) at 1/500 dilution in 1% BSA in PBST overnight at 4 ℃. Goat Anti-Mouse IgG H&L (iFluor™ 488, HA1125) was used as the secondary antibody at 1/1,000 dilution. PBS instead of the primary antibody was used as the secondary antibody only control. Nuclear DNA was labelled in blue with DAPI. beta Tubulin (ET1602-4, red) was stained at 1/100 dilution overnight at +4℃. Goat Anti-Rabbit IgG H&L (iFluor™ 594, HA1122) were used as the secondary antibody at 1/1,000 dilution. |
Note: All products are “FOR RESEARCH USE ONLY AND ARE NOT INTENDED FOR DIAGNOSTIC OR THERAPEUTIC USE”.
