AK3L1 Recombinant Rabbit Monoclonal Antibody [JE59-30]
cat.: HA720036
| Product Type: | Recombinant Rabbit monoclonal IgG, primary antibodies |
|---|---|
| Species reactivity: | Human |
| Applications: | WB, IF-Cell, IHC-P |
| Clonality: | Monoclonal |
| Clone number: | JE59-30 |
| Form: | Liquid |
| Storage condition: | Store at +4℃ after thawing. Aliquot store at -20℃. Avoid repeated freeze / thaw cycles. |
| Storage buffer: | 1*TBS (pH7.4), 0.05% BSA, 40% Glycerol. Preservative: 0.05% Sodium Azide. |
| Concentration: | 1ug/ul |
| Purification: | Protein A affinity purified. |
| Molecular weight: | Predicted band size: 25 kDa |
| Isotype: | IgG |
| Immunogen: | Recombinant protein within human AK3L1 aa 1-100/223. |
| Positive control: | HeLa cell lysate, HepG2 cell lysate, Raji cell lysate, HeLa, human kidney tissue, human liver tissue. |
| Subcellular location: | Mitochondrion matrix. |
| Recommended Dilutions:
WB IF-Cell IHC-P |
1:2,000 1:100 1:50-1:1,000 |
| Uniprot #: | SwissProt: P27144 Human |
| Alternative names: | Adenylate kinase 3 like 1 Adenylate kinase 3-like adenylate kinase 4 Adenylate kinase isoenzyme 4, mitochondrial AK3 AK3L1 AK3L2 AK4 ATP AMP transphosphorylase ATP-AMP transphosphorylase GTP:AMP phosphotransferase KAD4_HUMAN MGC166959 mitochondrial adenylate kinase 3 nucleoside-triphosphate adenylate kinase |
Images
|
Fig1:
Western blot analysis of AK3L1 on different lysates with Rabbit anti-AK3L1 antibody (HA720036) at 1/1,000 dilution. Lane 1: HAP1-parental cell lysate Lane 2: HAP1-AK3L1 KD cell lysate Lysates/proteins at 10 µg/Lane. Predicted band size: 25 kDa Observed band size: 30 kDa Exposure time: 10 seconds; ECL: K1801; 4-20% SDS-PAGE gel. Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (HA720036) at 1/1,000 dilution was used in K1803 at 4℃ overnight. Goat Anti-Rabbit IgG - HRP Secondary Antibody (HA1001) at 1/50,000 dilution was used for 1 hour at room temperature. |
|
Fig2:
Western blot analysis of AK3L1 on different lysates with Rabbit anti-AK3L1 antibody (HA720036) at 1/2,000 dilution. Lane 1: HeLa cell lysate Lane 2: HepG2 cell lysate Lane 3: Raji cell lysate Lysates/proteins at 20 µg/Lane. Predicted band size: 25 kDa Observed band size: 30 kDa Exposure time: 20 seconds; ECL: K1801; 4-20% SDS-PAGE gel. Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (HA720036) at 1/2,000 dilution was used in 5% NFDM/TBST at 4℃ overnight. Goat Anti-Rabbit IgG - HRP Secondary Antibody (HA1001) at 1/50,000 dilution was used for 1 hour at room temperature. |
|
Fig3:
Immunocytochemistry analysis of HeLa cells labeling AK3L1 with Rabbit anti-AK3L1 antibody (HA720036) at 1/100 dilution. Cells were fixed in 4% paraformaldehyde for 15 minutes at room temperature, permeabilized with 0.1% Triton X-100 in PBS for 15 minutes at room temperature, then blocked with 1% BSA in 10% negative goat serum for 1 hour at room temperature. Cells were then incubated with Rabbit anti-AK3L1 antibody (HA720036) at 1/100 dilution in 1% BSA in PBST overnight at 4 ℃. Goat Anti-Rabbit IgG H&L (iFluor™ 488, HA1121) was used as the secondary antibody at 1/1,000 dilution. PBS instead of the primary antibody was used as the secondary antibody only control. Nuclear DNA was labelled in blue with DAPI. Beta tubulin (HA601187, red) was stained at 1/100 dilution overnight at +4℃. Goat Anti-Mouse IgG H&L (iFluor™ 594, HA1126) was used as the secondary antibody at 1/1,000 dilution. |
|
Fig4:
Immunohistochemical analysis of paraffin-embedded human kidney tissue with Rabbit anti-AK3L1 antibody (HA720036) at 1/1,000 dilution. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (HA720036) at 1/1,000 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX. |
|
Fig5: Immunohistochemical analysis of paraffin-embedded human liver tissue using anti-AK3L1 antibody. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 8.0-8.4) for 20 minutes.The tissues were blocked in 5% BSA for 30 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (HA720036, 1/50) for 30 minutes at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX. |
Note: All products are “FOR RESEARCH USE ONLY AND ARE NOT INTENDED FOR DIAGNOSTIC OR THERAPEUTIC USE”.
