VISTA Recombinant Rabbit Monoclonal Antibody [PSH0-64]
cat.: HA721452
| Product Type: | Recombinant Rabbit monoclonal IgG, primary antibodies |
|---|---|
| Species reactivity: | Human |
| Applications: | WB, IHC-P |
| Clonality: | Monoclonal |
| Clone number: | PSH0-64 |
| Form: | Liquid |
| Storage condition: | Store at +4℃ after thawing. Aliquot store at -20℃. Avoid repeated freeze / thaw cycles. |
| Storage buffer: | PBS (pH7.4), 0.1% BSA, 40% Glycerol. Preservative: 0.05% Sodium Azide. |
| Concentration: | 1ug/ul |
| Purification: | Protein A affinity purified. |
| Molecular weight: | Predicted band size: 34 kDa |
| Isotype: | IgG |
| Immunogen: | Recombinant protein within human VISTA aa 1-194 / 311. |
| Positive control: | A431 cell lysate, A375 cell lysate, K-562 cell lysate, TF-1 cell lysate, human lung tissue lysate, human brain tissue, human placenta tissue, human tonsil tissue. |
| Subcellular location: | Cell membrane. |
| Recommended Dilutions:
WB IHC-P |
1:1,000 1:1,000 |
| Uniprot #: | SwissProt: Q9H7M9 Human |
| Alternative names: | B7 H5 B7H5 C10orf54 chromosome 10 open reading frame 54 DD1alpha GI24 GI24_HUMAN PD-1H PDCD1 homolog Platelet receptor Gi24 PP2135 sisp 1 SISP1 stress induced secreted protein 1 UNQ730/PRO1412 V domain Ig suppressor of T cell activation V set domain containing immunoregulatory receptor V set immunoregulatory receptor V type immunoglobulin domain containing suppressor of T cell activation VISTA |
Images
|
Fig1:
Western blot analysis of VISTA on different lysates with Rabbit anti-VISTA antibody (HA721452) at 1/1,000 dilution and competitor's antibody at 1/1,000 dilution. Lane 1: A431 cell lysate (20 µg/Lane) Lane 2: A375 cell lysate (20 µg/Lane) Lane 3: K-562 cell lysate (20 µg/Lane) Lane 4: TF-1 cell lysate (20 µg/Lane) Lane 5: MCF7 cell lysate (low expression) (20 µg/Lane) Lane 6: HEK-293 cell lysate (low expression) (20 µg/Lane) Lane 7: Human lung tissue lysate (30 µg/Lane) Predicted band size: 34 kDa Observed band size: 45-60 kDa (Glycosylated) Exposure time: 30 seconds; 4-20% SDS-PAGE gel. Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (HA721452) at 1/1,000 dilution and competitor's antibody at 1/1,000 dilution were used in 5% NFDM/TBST at 4℃ overnight. Goat Anti-Rabbit IgG - HRP Secondary Antibody (HA1001) at 1/50,000 dilution was used for 1 hour at room temperature. |
|
Fig2:
Western blot analysis of VISTA on different lysates with Rabbit anti-VISTA antibody (HA721452) at 1/1,000 dilution. Lane 1: A431-si NT cell lysate Lane 2: A431-si VISTA cell lysate Lysates/proteins at 10 µg/Lane. Predicted band size: 34 kDa Observed band size: 45-60 kDa (Glycosylated) Exposure time: 28 seconds; 4-20% SDS-PAGE gel. Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (HA721452) at 1/1,000 dilution was used in 5% NFDM/TBST at 4℃ overnight. Goat Anti-Rabbit IgG - HRP Secondary Antibody (HA1001) at 1/50,000 dilution was used for 1 hour at room temperature. |
|
Fig3:
Western blot analysis of VISTA on different lysates with Rabbit anti-VISTA antibody (HA721452) at 1/1,000 dilution. Lane 1: THP-1 cell lysate Lane 2: THP-1 cell lysate treated with deglycosylation Lysates/proteins at 20 µg/Lane. Predicted band size: 34 kDa Observed band size: 34/45-60 kDa (Glycosylated) Exposure time: 40 seconds; 4-20% SDS-PAGE gel. Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (HA721452) at 1/1,000 dilution was used in 5% NFDM/TBST at 4℃ overnight. Goat Anti-Rabbit IgG - HRP Secondary Antibody (HA1001) at 1/50,000 dilution was used for 1 hour at room temperature. |
|
Fig4:
Immunohistochemical analysis of paraffin-embedded human brain tissue with Rabbit anti-VISTA antibody (HA721452) at 1/1,000 dilution. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (HA721452) at 1/1,000 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX. |
|
Fig5:
Immunohistochemical analysis of paraffin-embedded human placenta tissue with Rabbit anti-VISTA antibody (HA721452) at 1/1,000 dilution. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (HA721452) at 1/1,000 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX. |
|
Fig6:
Immunohistochemical analysis of paraffin-embedded human tonsil tissue with Rabbit anti-VISTA antibody (HA721452) at 1/1,000 dilution. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (HA721452) at 1/1,000 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX. |
Note: All products are “FOR RESEARCH USE ONLY AND ARE NOT INTENDED FOR DIAGNOSTIC OR THERAPEUTIC USE”.
