ERK1 Mouse Monoclonal Antibody [7-D6-E5]
cat.: M1505-9
Product Type: Mouse monoclonal IgG1, primary antibodies
Species reactivity: Human, Mouse, Rat
Applications: WB, IF-Cell, IHC-P
Clonality: Monoclonal
Clone number: 7-D6-E5
Form: Liquid
Storage condition: Shipped at 4℃. Store at +4℃ short term (1-2 weeks). It is recommended to aliquot into single-use upon delivery. Store at -20℃ long term.
Storage buffer: 1*PBS (pH7.4), 0.2% BSA, 40% Glycerol. Preservative: 0.05% Sodium Azide.
Concentration: 2ug/ul
Purification: Protein A affinity purified.
Molecular weight: Predicted band size: 43 kDa
Isotype: IgG1
Immunogen: Synthetic peptide within Human ERK1 aa 301-350 / 379.
Positive control: Hela cell lysates, MCF-7, human breast carcinoma tissue, mouse esophagus tissue, mouse stomach tissue, RAW264.7, C6.
Subcellular location: Cytoplasm, Nucleus, Membrane, caveola, Cell junction, focal adhesion.
Recommended Dilutions:
  WB
  IF-Cell
  IHC-P
1:5,000-1:10,000
1:50-1:200
1:3,000
Uniprot #: SwissProt: P27361 Human | Q63844 Mouse | P21708 Rat
Alternative names: ERK 1 ERK ERK-1 ERK1 ERT 2 ERT2 Extracellular Signal Regulated Kinase 1 Extracellular signal related kinase 1 Extracellular signal-regulated kinase 1 HGNC6877 HS44KDAP HUMKER1A Insulin Stimulated MAP2 Kinase Insulin-stimulated MAP2 kinase MAP kinase 1 MAP kinase 3 MAP Kinase MAP kinase isoform p44 MAPK 1 MAPK 3 MAPK MAPK1 Mapk3 MGC20180 Microtubule Associated Protein 2 Kinase Microtubule-associated protein 2 kinase Mitogen Activated Protein Kinase 3 Mitogen-activated protein kinase 1 Mitogen-activated protein kinase 3 MK03_HUMAN OTTHUMP00000174538 OTTHUMP00000174541 p44 ERK1 p44 MAPK p44-ERK1 p44-MAPK P44ERK1 P44MAPK PRKM 3 PRKM3 Protein Kinase Mitogen Activated 3
Images
M1505-9_1.jpg Fig1: Western blot analysis on Hela cell lysates using anti-ERK1 mouse mAb.
M1505-9_2.jpg Fig2: Immunocytochemistry analysis of MCF-7 cells labeling ERK1 with Mouse anti-ERK1 antibody (M1505-9) at 1/50 dilution.

Cells were fixed in 4% paraformaldehyde for 30 minutes, permeabilized with 0.1% Triton X-100 in PBS for 15 minutes, and then blocked with 2% BSA for 30 minutes at room temperature. Cells were then incubated with Mouse anti-ERK1 antibody (M1505-9) at 1/50 dilution in 2% BSA overnight at 4 ℃. Goat Anti-Mouse IgG H&L (iFluor™ 488, HA1125) was used as the secondary antibody at 1/1,000 dilution. PBS instead of the primary antibody was used as the secondary antibody only control. Nuclear DNA was labelled in blue with DAPI.
M1505-9_3.jpg Fig3: Immunohistochemical analysis of paraffin-embedded human breast carcinoma tissue with Mouse anti-ERK1 antibody (M1505-9) at 1/3,000 dilution.

The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH 6.0) (high pressure) for 2 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (M1505-9) at 1/3,000 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.
M1505-9_4.jpg Fig4: Immunohistochemical analysis of paraffin-embedded mouse esophagus tissue with Mouse anti-ERK1 antibody (M1505-9) at 1/3,000 dilution.

The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH 6.0) (high pressure) for 2 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (M1505-9) at 1/3,000 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.
M1505-9_5.jpg Fig5: Immunohistochemical analysis of paraffin-embedded mouse stomach tissue with Mouse anti-ERK1 antibody (M1505-9) at 1/3,000 dilution.

The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH 6.0) (high pressure) for 2 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (M1505-9) at 1/3,000 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.
M1505-9_6.jpg Fig6: Immunocytochemistry analysis of RAW264.7 cells labeling ERK1 with Mouse anti-ERK1 antibody (M1505-9) at 1/100 dilution.

Cells were fixed in 4% paraformaldehyde for 15 minutes at room temperature, permeabilized with 0.1% Triton X-100 in PBS for 15 minutes at room temperature, then blocked with 1% BSA in 10% negative goat serum for 1 hour at room temperature. Cells were then incubated with Mouse anti-ERK1 antibody (M1505-9) at 1/100 dilution in 1% BSA in PBST overnight at 4 ℃. Goat Anti-Mouse IgG H&L (iFluor™ 488, HA1125) was used as the secondary antibody at 1/1,000 dilution. PBS instead of the primary antibody was used as the secondary antibody only control. Nuclear DNA was labelled in blue with DAPI.

beta Tubulin (ET1602-4, red) was stained at 1/100 dilution overnight at +4℃. Goat Anti-Rabbit IgG H&L (iFluor™ 594, HA1122) were used as the secondary antibody at 1/1,000 dilution.
M1505-9_7.jpg Fig7: Immunocytochemistry analysis of C6 cells labeling ERK1 with Mouse anti-ERK1 antibody (M1505-9) at 1/100 dilution.

Cells were fixed in 4% paraformaldehyde for 15 minutes at room temperature, permeabilized with 0.1% Triton X-100 in PBS for 15 minutes at room temperature, then blocked with 1% BSA in 10% negative goat serum for 1 hour at room temperature. Cells were then incubated with Mouse anti-ERK1 antibody (M1505-9) at 1/100 dilution in 1% BSA in PBST overnight at 4 ℃. Goat Anti-Mouse IgG H&L (iFluor™ 488, HA1125) was used as the secondary antibody at 1/1,000 dilution. PBS instead of the primary antibody was used as the secondary antibody only control. Nuclear DNA was labelled in blue with DAPI.

beta Tubulin (ET1602-4, red) was stained at 1/100 dilution overnight at +4℃. Goat Anti-Rabbit IgG H&L (iFluor™ 594, HA1122) were used as the secondary antibody at 1/1,000 dilution.
Note: All products are “FOR RESEARCH USE ONLY AND ARE NOT INTENDED FOR DIAGNOSTIC OR THERAPEUTIC USE”.
